The equipment adopts advanced PLC control, which makes the machine more speed and stable. In addition, automatic functions such as safe and humanized design, precise cutting, one-time forming, automatic fault alarm, counting, and paper detection are adopted.
| Model | JC-WTJ-180 |
| Paper Lid Forming Size |
（T）: 55~145mm （H): 8~15mm |
| Diameter | Φ55-Φ145mm |
| Forming Height | 8-15mm |
| Machine Speed | 70-90pcs/min |
| Machine Net Weight | 2900kg |
| Power Supply | 380V 50Hz |
| Equipment Power | 17Kw |
| Machine Size | 3250*1400*1950mm |
| Paper Grams |
250-350gsm single and double coated paper, raruish and coated, coated paper |
| Working Air Pressure | 0.3Mpa , 0.02m³/minute |
